JX servo RD-5606HB 6kg 300 degree Digital Servo Robotics Education Industrial

Name: JX servo RD-5606HB 6kg 300 degree Digital Servo Robotics Education Industrial
Brand: Be Great RC
SKU: BR0052.0104
Price: 3.44 USD
Availability: InStock

SKU: BR0052.0104

This item is available by special order only. For pricing, MOQ and delivery information, please contact your sales representative.

~~$9.00~~ $3.44 Login to see price

Received successfully

Coupon Code

CONTINUE SHOPPING

Add to Favorites (1)

1/1

Description

FEATURE:
-- High performance robot servo
-- High quality core motor
-- 300° angle

SPECIFICATIONS:
Dead band: 4μs
Neutral point: 1500μs
Pulse width：500μs-2500μs
Motor: Core
Max angle：300°±2°
Frequence: 330hz
Operating Voltage：4.8V-6V
Operating Speed(4.8V): 0.14sec/60°
Operating Speed(6.0V): 0.12sec/60°
Stall torque(4.8V): 5.50kg.cm
Stall torque(6.0V): 6.20kg.cm
Demension: 40.5X20.3X40mm
Weight: 47 g
Connector Wire Length: JR 200mm
Spline Count: 25T
