Discover the SV10-12A & SV10-12B, the SHV high-performance coreless servo designed for RC Gliders, and Industrial UAVs. The SV10-12 excels with higher torque (14.0Kgf.cm at 13V) and faster response (0.10sec/60°), making it perfect for high-load applications. It feature hardened steel gears, aluminium alloy casing, and programmable soft start, operating at 1520μs/333Hz with a default travel of ±60°. Choose the SV10-12 for higher performance, or the SV10M-12 for lightweight, compact solutions tailored to your needs.
The SV10-12 servo is available in two different mounting tab options:
SV10-12A (Horizontal) / SV10-12B (Standard), this ensures flexibility to meet your installation preferences and requirements.
Features
SHV (Super High Voltage) DC 12V or Up to 3S LiPo Direct Drive
Supports 8.4-13.0V
High Torque & Exceptional Speed
Programmable
Large Default Travel Angle (programmable)
High Performance Coreless DC Motor
Hardened Steel Gear
Ideal RC Gliders and Industrial UAVs
Specification
Item: SV10-12 Servo
Nominal Rated Voltage: DC12.0V
Voltage Range: DC8.4V-13.0V
Torque: 11.0Kgf.cm@8.4V / 13.0Kgf.cm@12.0V / 14.0Kgf.cm@13.0V
Speed: 0.15sec/60°@8.4V / 0.11sec/60°@12.0V / 0.10sec/60°@13.0V
Working Frequency: 1520μs/333Hz
Default Travel Angle: ±60° = 120° Total
Temperature Range: -10℃.......+65℃
Soft Start: Programmable
Programmable: Yes
Case Material: Aluminium Alloy
Motor Type: Coreless DC Motor
Gear Set Material: Hardened Steel
Position Sensor: Potentiometer
Case Dimensions: 30*10*33.5mm±0.2mm
Weight: 25g±10%
Package Includes
1 * SV10-12 Servo (SV10-12A / SV10-12B)
2 * Plastic Servo Horn
1 * Servo Horn Screw
4 * Mounting Screw
