8 Channels Output: Supports SBUS + PWM for versatile compatibility.
3ms Low Latency: Achieved when paired with RC8X using digital servos.
Integrated Gyro: With adjustable sensitivity for enhanced driving stability.
Real-Time Telemetry: Monitors battery voltage, RSSI, and receiver voltage (supports up to 8S, 33.6V).
IPX4 Waterproof: PCB and pins are nano-coated for splash protection.
600 Meters Control Distance: Stable long-range signal transmission on ground.
FHSS Protocol: 67-channel pseudo-random frequency hopping for anti-interference.
Wide Transmitter Compatibility: Works with RC8X, RC6GS V2/V3, RC4GS V2/V3, T8FB, T8S, and more.
Channels:8
Antenna Length:205mm (8.07")
Dimensions:35 × 24 × 13.5 mm (1.38” × 0.94” × 0.53”)
Weight:10.5g (0.37oz)
Signals Output:SBUS + PWM
Operating Voltage:3 – 12V
Operating Current:35mA @ 5V
Frequency Band:2.4GHz ISM Band (2400MHz–2483.5MHz)
Spread Spectrum Mode:FHSS, 67 channels pseudo-random frequency hopping
Section Precision:4096, 0.25μs per section
Response Time:3ms (with RC8X)
Telemetry Function:Model battery voltage, RSSI, receiver voltage (max 8S / 33.6V)
Gyro Sensitivity:Adjustable via transmitter switch (e.g., PS3 on RC8X)
Waterproof Rating:IPX4 nano-coating on PCB and pins
Applicable Models:RC Cars (Crawler, Tank, Drift), Boats, Robots
Control Distance:Up to 600 meters (ground)
Compatible Transmitters:RC8X, RC6GS V3/V2, RC4GS V3/V2, RC6GS, RC4GS, T8FB, T8S (BT & OTG versions)
