| Video Output Port |
Ethernet Micro-HDMI CVBS (AV) |
| Control Signal Input Port |
S.Bus, UART Ethernet UDP |
| Control Signal Output Port |
S.Bus |
| High-Accuracy 3-Axis Stabilization |
Yaw, Pitch, Roll |
| Working Voltage |
11 ~ 25.2 V (Early manufacturing lots before June, 2023 were 11 ~ 16.5 V, please carefully confirm if you need 25.2 V input) |
| Power Consumption |
Average: 5W Summit: 12W |
| Working Temperature |
-10° ~ 50°C |
| Dimension |
55*55*70 mm |
| Weight |
95 g |
| Angular Vibration Range |
± 0.01° |
| Controllable Pitch Angle |
-135° ~ +45° |
| Controllable Yaw Angle |
-160° ~ +160° |
| Roll Angle |
-30° ~ +30° |
| Lens |
Fixed Focal Length 6X Digital Zoom |
| Equivalent Focal Length |
21 mm |
| Image Sensor |
Sony 1/1.7-inch, 8 MP effective resolution |
| Aperture |
F2.8 |
| FOV |
Diagonal: 93°, Horizontal: 81° |
| Video Recording Resolution |
4K (4096 × 2160) @ 25 fps 2K (2560 × 1440) @ 30 fps 1080p (1920 × 1080) @ 30 fps 720p (1280 × 720) @ 30 fps |
| Video Storage Bitrate (H265 Codec) |
4K / 2K: 20 Mbps 1080p / 720p: 15 Mbps |
| File Storage Format |
FAT32 ExFAT |
| Image Format |
JPG |
| Video Format |
MP4 |
| Supported MicroSD Cards |
MicroSD Class10, max 512 GB |
| Still Photography Mode |
Single |
| White Balance |
Auto |
